ISG (Idle Stop & Go) System - 2.0L: Alternator: Specifications: Specification

• 13.5V, 150A

Item	Specification
Rated voltage	13.5V, 150A
Speed in use	0 - 18, 000 rpm
Pin	1
Voltage regulator	IC Regulator built in type
Default regulated voltage (V) [COM terminal]	14.25 - 15.65 [-40°C (31°F)]
	14.25 - 14.65 [25°C (77°F)]
	14.25 - 14.65 [150°C (284°F)]
Pully Type	OAP

Courtesy of HYUNDAI MOTOR AMERICA
