Diagnostic Flowchart

G14719947Courtesy of HYUNDAI MOTOR AMERICA
NOTE: Replace the throttle body assembly or Engine Control Module (ECM). Then initialize the throttle position and perform the learning process again. Clear the previous TPS learnt value with the GDS.
