Sensor-A/C Pressure-Roof


Component ID: 437
Component : SENSOR-A/C PRESSURE-ROOF

Connector:
Name : SENSOR-A/C PRESSURE-ROOF
Color :
# of pins : 3




Pin Description Circuit
1 MINUS REFRIGERANT PRESSURE SENSOR 3796 20BR/OR
2 SIGNAL-REFRIGERANT PRESSURE SENSOR 3795 20DG
3 PLUS REFRIGERANT PRESSURE SENSOR 3797 20DB/RD
