Blower Motor Resistor

Component ID: 305
Component : REGULATOR-BLOWER MOTOR

Connector:
Name : REGULATOR-BLOWER MOTOR
Color :
# of pins : 4
Qualifier : (ATC)




Pin Description Circuit
1 GROUND 10BR
2 - 20GY
3 BLOWER MOTOR CONTROL 10BR
4 FUSED B(+) U162 10RD/WT
