Air Injection Pump Relay

Component ID: 315
Component : RELAY-ELECTRIC AIR PUMP

Connector:
Name : RELAY-ELECTRIC AIR PUMP
Color :
# of pins : 4




Pin Description Circuit
1 ELECTRIC AIR PUMP CONTROL 1685 18DB/BR
2 FUSED MAIN RELAY OUTPUT U798 18BK/YL
3 AIR PUMP RELAY OUTPUT 3583 8BK
4 BUSED B+ 3581 8RD
