Driver Door Window Control Switch: Removal

NOTE: Left hand drive (LHD) shown below, right hand drive (RHD) similar.
  1. Remove the front door trim panel. Refer to: Front Door Trim Panel .
  2. Remove the driver door window control switch.

    1. Disconnect the electrical connector from the driver door window control switch.
    2. Remove the screws from driver door window control switch.
    3. Remove the driver door window control switch from the bezel assembly.

GFD610669Courtesy of FORD MOTOR COMPANY
