Fog Lamp: Notes

WARNING: This page is about a different car, the 2014 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: For information on Ford Color Coded Illustrations refer to COLOR-CODING - FORD .

Fig 1: Fog Lamp Assembly, Bolts And Electrical Connector With Torque Specifications

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	-	Fog lamp electrical connector (part of 12A581)
2	W505424	Fog lamp bolts (3 required)
3	15200/15201	Fog lamp assembly (RH/LH)
