Connecting Rod, Engine





Connecting Rod Cap Bolts
Stage 1: Tighten to 43 Nm (32 ft. lbs.).
Stage 2: Tighten an additional 105 degrees.

Connecting Rod

Rod bearing-to-journal clearance 0.064-0.026 mm
