Reverse Clutch: Material

MATERIAL SPECIFICATION

Item Specification
Automatic Transmission Fluid XT-5-QM MERCON®
Fig 1: Identifying Reverse Clutch Components
G03192516Courtesy of FORD MOTOR CO.
