General Description

Ignition System:

FEATURES
In the Electronic Ignition System, all engine timing and spark distribution is electronic with no moving parts.

COMPONENTS
- Powertrain Control Module (PCM).
- Crankshaft Position (CKP) sensor.
- Ignition Coils.
- Spark Plugs
- Related Wiring.

OPERATION
Using related sensor inputs, the Powertrain Control Module determines the ignition timing required by the engine and determines which ignition coil to use.
