Module-Drive Style

Harness-Family: Body_Front

Color:

Gender: FEMALE

Part Number: AGV3079

Part Description: Not Available

Connector No: D2538

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Module-Drive Style Component Location

GCWD1179034

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

Z910

BK

22

GROUND

N/A

2

T403

WT/VT

22

TRANSMISSION DRIVE SIGNAL

N/A

4

F991

DB/WT

22

FUSED IGNITION RUN/ACCESSORY CONTROL OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
