Module-Body Control C1

Harness-Family: Body_Front

Color: BLACK

Gender: FEMALE

Part Number: AGV95373

Part Description: - -

Connector No: D2962A

Option:

Cavity Count: - -

Fig 1: Module-Body Control C1 Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Body Control C1 Connector Location View

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	X3	DG/WT	22	HORN SWITCH SENSE	N/A
4	L139	VW/WT	22	FRONT FOG LAMP RELAY CONTROL	N/A
5	G75	YL/DB	22	DRIVER DOOR AJAR SWITCH SENSE	N/A
6	C515	BR/DB	22	REAR WINDOW DEFOGGER RELAY OUTPUT	N/A
8	L60	DB/BK	20	RIGHT FRONT TURN LAMP DRIVER	LATAM
8	L60	DB/BK	22	REAR FRONT TURN LAMP DRIVER	NAFTA
10	L61	DB/WT	20	RIGHT FRONT TURN LAMP DRIVER	LATAM
10	L61	DB/WT	22	LEFT FRONT TURN LAMP DRIVER	NAFTA
12	E16	YL	22	PANEL LAMPS DRIVER	N/A
13	L59	DG/YL	20	RIGHT DRL LAMP DRIVER	N/A
15	L78	YL/BK	22	RIGHT FRONT PARK LAMP DRIVER	N/A
22	L300	VT/OR	22	HIGH BEAM HEADLAMP RELAY CONTROL	N/A
23	L239	VT/WT	22	REAR FOG LAMP RELAY CONTROL	N/A
24	P4	VT/DB	22	PASSANGER DOOR UNLOCK DRIVER	N/A
27	L56	DG/WT	22	BRAKE LAMP SWITCH OUTPUT	N/A
28	L58	DG/YL	20	LEFT DRL LAMP DRIVER	N/A
29	L77	YL/RD	22	LEFT FRONT PARK LAMP DRIVER	N/A
31	P133	WT/BK	22	DRIVER HEATED SEAT RELAY CONTROL	N/A
33	B20	WT/DB	22	BRAKE FLUID LEVEL SIGNAL	N/A
34	B134	DG/BK	22	BRAKE SIGNAL 2	N/A
35	X920	DB/BR	22	RADIO CONTROL MUX RETURN	N/A
37	G931	VT/DG	22	SENSOR GROUND	N/A
39	W4	WT/GY	22	WIPER HIGH SPEED CONTROL OUTPUT	N/A
44	D65	DG	22	CAN C (+)	N/A
45	D64	BR	22	CAN C (-)	N/A
46	P134	WT/RD	22	PASSENGER HEATED SEAT RELAY CONTROL	N/A
49	C28	BR/DG	22	A/C CLUTCH CONTROL	N/A
51	P3	VT/RD	22	DRIVER DOOR LOCK DRIVER	N/A
52	G31	BK/VT	22	AAT SIGNAL	N/A
53	G74	WT/RD	22	PASSENGER DOOR AJAR SWITCH SENSE	N/A
54	G75	WT/VT	22	DRIVER DOOR AJAR SWITCH SENSE	N/A
57	D42	WT	22	CAN B (-)	N/A
58	D41	DB	22	CAN B (+)	N/A
