SWITCH, Power Window: Installation: Installation: Front

Fig 1: Removing/Installing Front Power Window Switch
GC0114261Courtesy of CHRYSLER LLC
  1. Install switch into bezel.
  2. Connect electrical harness connector to switch.
  3. Install bezel. Refer to Body/Instrument Panel/BEZEL, Instrument Cluster - Installation .
  4. Connect battery negative cable.
