Installation

4.0L




1. Install camshaft sensor.

2. Install the mounting bolts and tighten to 12 Nm (106 in.lbs.)

3. Install and lock the camshaft sensor electrical connector.




4. Install makeup air hose.

5. Connect the negative battery cable.
