Body Control Module Connector End View (C3)

BODY CONTROL MODULE C3 - BLACK 9-WAY

Courtesy of CHRYSLER CORP.
CAV	CIRCUIT	FUNCTION
45	16BK/BL	TURN SIGNAL MONITORED GROUND
46	16BK/YL	HAZARD SWITCH SIGNAL
47	22DG/BL	REAR DEFOGGER SWITCH SENSE
48	22DG/BK	REAR DEFOGGER INDICATOR DRIVER
49	20WT/DG	DOOR LOCK SWITCH MUX
63	16GY	WASHER PUMP MOTOR CONTROL
64	-	-
65	18BL	WIPER SWITCH MUX
66	-	-
