Sensor-Wheel Speed-Abs-Front: Installation

WARNING: This page is about a different car, the 2005 Dodge Durango. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Removing Front Wheel Speed Sensor
GC0006391Courtesy of DAIMLERCHRYSLER CORP.
  1. Install the wiring to the clips and Reconnect the electrical connector.
  2. Install the wheel speed sensor (2) to the hub (3).
  3. Install the wheel speed sensor mounting bolt (1) to the hub (3). Tighten the bolt to 21 N.m (190 in. lbs.).
  4. Install the front rotor and brake caliper assembly (Refer to BRAKES/HYDRAULIC/MECHANICAL/ROTORS - INSTALLATION) .
