Rear Window Defogger Relay: Removal
- Disconnect the battery negative remote cable from the remote ground post (Fig 1
).
Courtesy of DAIMLERCHRYSLER CORP.
- Open the trunk. Remove the carpeting fasteners from the right rear panel and pull the trunk carpeting away:
- Remove the relay fastener screw and unplug the relay.
- Remove the relay from vehicle.
