Driver Information Display and Multifunction Switch Replacement

Fig 1: Driver Information Display and Multifunction Switch
GM2382387Courtesy of GENERAL MOTORS COMPANY
Driver Information Display and Multifunction Switch Replacement

Callout Component Name
1 Instrument Panel Outer Air Outlet Assembly
Procedure
Refer to Instrument Panel Outer Air Outlet Replacement - Left Side .
2 Driver Information Display and Multifunction Switch Assembly
Procedure
Unsnap the switch assembly from the instrument panel outer air outlet.
