Windshield Washer Solvent Level Switch Replacement
WARNING: This page is about a different car, the 2015 Cadillac SRX. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of GENERAL MOTORS COMPANY
| Callout |
Component Name |
Preliminary Procedure
Remove the left front wheelhouse liner. Refer to Front Wheelhouse Liner Replacement
. |
| 1 |
Windshield Washer Level Sensor Switch Procedure
- Drain the windshield washer solvent into a suitable clean container.
- Disconnect the electrical connector to the level sensor switch.
- Using 2 suitable flat-bladed tools, remove the level sensor switch from the windshield washer container.
- Discard the level sensor grommet.
|
