Installation Procedure

WARNING: This page is about a different car, the 2011 Chevrolet Cruze. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Windshield Washer Pump Components
    GM2027123Courtesy of GENERAL MOTORS CORP.
  1. Position the washer pump terminal seal (4) to the washer solvent container (5), pressing in until fully seated.
  2. Using full strength windshield washer solvent as a lubricant on the terminal seal, position the washer pump (3) to the washer solvent container (5) pressing in until fully seated.
  3. Connect the washer pump electrical connector (1).
  4. Connect the washer pump hose (2) to the washer pump (5).
  5. Install the front wheelhouse liner. Refer to Front Wheelhouse Liner Replacement .
  6. Fill the washer solvent container with washer solvent.
  7. Inspect the washer system for proper operation.
