Passenger Compartment/Roof Component Views



Passenger Compartment/Roof Component Views

Passenger Presence System (PPS) Components 1 of 2




1 - Radio
2 - Heated Seat Switch-Passenger (KA1)
3 - HVAC Control Module
4 - Heated Seat Switch-Driver (KA1)
5 - Inflatable Restraint PASSENGER AIR BAG ON/OFF Indicator
