Installation Procedure

  1. Install the multifunction alarm (1) to the rear of the instrument cluster (2). Secure the alarm with the retainer.
  2. Install the instrument cluster. Refer to INSTRUMENT PANEL CLUSTER (IPC) REPLACEMENT .
  3. Connect the negative battery cable.
    Fig 1: Multifunction Alarm Module
    G01407845Courtesy of GENERAL MOTORS CORP.
