Wiper Switch: Service and Repair

Fig. 7 Windshield Wiper Switch Replacement. Except Tilt Column:

Fig. 8 Windshield Wiper Switch Replacement. Tilt Column:

1. Remove ignition lock as described under INSTRUMENT PANELS AND CLUSTERS/COMPONENT REPLACEMENT AND REPAIR PROCEDURES/IGNITION LOCK.
2. Refer to Figs. 7 and 8 to replace wiper switch. Reverse procedure to install.
