Step/Running Board Component Views
Fig 1: Retractable Running Board Components (BRS)
Courtesy of GENERAL MOTORS CORP.
Callout
Component Name
1
Front Exhaust
2
Transmission
3
Running Board - Right
4
Articulating Running Board Module (ARBM)
5
Running Board - Left
