Note On Intermittents

If intermittent Code B124 is being set, manipulate related wiring while observing BCM parameter BD60. If a failure is induced, reading will jump from normal value to zero MPH.

Fig 1: BCM Code B124 Circuit Diagram

Fig 2: BCM Code B124 Flow Chart
