Rearview Driver Information Camera Replacement (Hatchback)
July 1:
So it begins
. Don't worry, this is not in the correct legal jurisdiction!
Rearview Driver Information Camera Replacement (Hatchback)
Callout
Component Name
1
Rearview Driver Information Camera Bolt [2x]
CAUTION:
Fastener Caution
Tighten
2.5 N.m (22 lb in)
2
Rearview Driver Information Camera
Procedure
Disconnect the electrical connector.
Release the retaining tabs.
