Section 11 (Anti-Lock Brake System (Fwd)): Description: Notes
WARNING: This page does not describe the selected car, but rather 14 other vehicles, including the 1990 Pontiac Bonneville, 1990 Oldsmobile Ninety-Eight, 1990 Oldsmobile Eighty-Eight, 1990 Cadillac Fleetwood, and 1990 Cadillac DeVille. However, it is still accessible from the selected car via links, so may be relevant.
The Teves 4-wheel Anti-Lock Brake System (ABS) is designed to prevent wheel lock-up during heavy braking. This allows driver to maintain steering control while stopping vehicle in shortest distance.
Major components include: pump motor assembly, hydraulic accumulator, pressure switch, fluid reservoir with integral filter, 4 wheel speed sensors, valve block assembly, fluid level sensor, Electronic Brake Control Module (EBCM), hydraulic booster/master cylinder assembly, and "BRAKE" and "ANTI-LOCK" warning lights. See Figure .
