Front Passenger Air Bag Assembly

The front airbag is designed to protect the head and upper part of the body in the event of a frontal impact. The assemblies consist of a gas generator, ignition pill and the folded airbag.

Fig 1: Identifying Front Passenger Air Bag Assembly
G03403416Courtesy of BMW OF NORTH AMERICA, INC.
