Dynamic Steering Assembly Overview

  1. Electromechanical power steering motor -V187-
  2. Active steering control module -J792-
    • The active steering control module is located in the footwell in front of the driver seat.
  3. Power Steering Pump -V119-
    • With An Electric Control Valve
G12770731Courtesy of AUDI OF AMERICA, LLC
