Radiator Shutter, Removing And Installing: Installing

WARNING: This page is about a different variant/trim than selected.

Install in reverse order of removal. Note the following:

-- Make sure the guides for the radiator shutter -2- sit correctly on the impact member -1- -arrow-.

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- The radiator shutter must be adapted if it is replaced.

-- Adapt the Radiator Shutter Motor -V544- using the Vehicle Diagnostic Tester.
