Air Suspension, Checking Sealing Boots For Leaks And Damage

Procedure

-- Check all four suspension struts -arrow- for the air suspension for damage and leaks.

Fig 1: Identifying Suspension Struts -Arrow- For Air Suspension

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

NOTE:

If damage or leaks are determined, these must be checked. This is a repair procedure and must be discussed with the customer.
