Module-Transmission Control (D3855)

Harness-Family: Powertrain

Color: GRAY

Gender: FEMALE

Part Number: 1-1924939-5

Part Description: Not Available

Connector No: D3855

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 96

Fig 1: Module-Transmission Control Connector End View
GCWD1080890Courtesy of CHRYSLER
Fig 2: Module-Transmission Control Component Location
GCWD1191614Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 T20 DG/WT 16 L/R CONTROL N/A
2 T82 DG/OR 16 DC CONTROL N/A
3 T80 DG/YL 16 LC CONTROL N/A
4 T59 YL/LB 16 UD CONTROL N/A
5 T60 YL/GY 16 OD CONTROL N/A
7 T15 YL/BR 18 TRANSMISSION CONTROL N/A
8 T85 DG/LG 18 TRANSFER SPEED SIGNAL N/A
9 T13 DG/VT 18 SPEED SENSOR GROUND N/A
10 T52 DG/WT 18 INPUT SPEED SIGNAL N/A
14 T47 YL/DG 18 2-4 PRESSURE SIGNAL N/A
16 T5 DG/YL 18 AUTOSTICK UPSHIFT SIGNAL N/A
20 T38 YL/BR 18 LINE PRESSURE SIGNAL N/A
23 F202 PK/GY 18 IGNITION RUN/START CONTROL OUTPUT N/A
25 T19 DB/YL 16 2-4 CONTROL N/A
26 T16 YL/OR 16 TRANSMISSION CONTROL OUTPUT N/A
27 T16 YL/OR 16 TRANSMISSION CONTROL OUTPUT N/A
28 T16 YL/OR 16 TRANSMISSION CONTROL OUTPUT N/A
29 T118 DG 16 LP VFS CONTROL N/A
33 D64 WT/LB 18 CAN C (-) N/A
34 T14 DG/BR 18 OUTPUT SPEED SIGNAL N/A
37 T83 DG/GY 18 DC PRESSURE SIGNAL N/A
38 T81 DG/LB 18 LC PRESSURE SIGNAL N/A
39 T1 DG/LB 18 TRS T1 SIGNAL N/A
40 T44 YL/DG 18 AUTOSTICK DOWNSHIFT SIGNAL N/A
44 T54 DG/OR 18 TRANSMISSION TEMPERATURE SIGNAL N/A
45 K900 DB/DG 18 SENSOR GROUND N/A
47 F1 PK/WT 18 IGNITION OFF/RUN/START CONTROL OUTPUT N/A
49 Z901 BK 16 GROUND N/A
50 Z901 BK 16 GROUND N/A
51 Z901 BK 16 GROUND N/A
52 Z901 BK 16 GROUND N/A
53 Z901 BK 16 GROUND N/A
57 D65 WT/BK 18 CAN C (+) N/A
60 T50 YL/TN 18 L/R PRESSURE SIGNAL N/A
61 T9 DG/TN 18 OD PRESSURE SIGNAL N/A
62 T3 DG/DB 18 TRS T3 SIGNAL N/A
69 K856 BR/YL 18 5 VOLT SUPPLY N/A
72 Z901 BK 16 GROUND N/A
73 T84 DG/TN 16 EMCC CONTROL N/A
87 T41 YL/DB 18 TRS T41 SIGNAL N/A
88 T42 DG/YL 18 TRS T42 SIGNAL N/A
96 A209 RD 18 FUSED B(+) N/A
(1) Pins not listed are not used for this connector
