Windshield Assembly Overview
WARNING: This page is about a different variant/trim than selected.
- Windshield
- Removing and installing, refer to WINDSHIELD
- PUR adhesive sealant
- Bead cross section: -Width b- = 6.5 mm -Height a- Height = 10 mm (including the precoating, residual material on the window and the window flange)
- Minimum curing time, refer to MINIMUM CURING TIME
- Body flange
- Window adjuster
- 443, 845, 631 A
- Retainer
- is a part of the windshield
- Plenum chamber cover
- Must only be pulled out of binding profile by hand.
- Removing, refer to PLENUM CHAMBER COVER
- Adhesive bead end
- Apply the adhesive bead in this area
