Generator carbon brushes, checking

Lengths of carbon brushes:

• New: 12 mm (0.47 in)
• In-service: minimum 5 mm (0.20 in) (wear limit)
• Tolerance: + 1 mm (+ 0.04 in)
  Fig 1: Identifying Generator Carbon Brushes

  Courtesy of VOLKSWAGEN OF AMERICA, INC.
